ST-640E Online Networked System

Features

◆ 1000 users, 4 digit PIN codese

◆ Auto rest function

◆ Security system settings enabled /disabled

◆ Synchronizes with security system

◆ 3 Access modes: Card only, Card or Card, and Card with Code

◆ Alarm outputs: Duress, Door Ajar, Forced Entry

◆ Red, green and yellow LEDs for status and programming feedback

◆ Request to Exit input and door sensor input

◆ Timed relay outputs or latching (on/off)

◆ Management system software included

◆ Mounts to ANSI standard surface or recessed single-gang boxes

Specifications

◆ Voltage: 12 VDC

◆ Keypad Output: 26-bit/34-bit Wiegand

◆ Read Range: 10 ~15 cm

◆ Proximity Frequency: EM 125KHz

◆ Temperature: 23°F ~140°F (-5°C~+60°C)

◆ Humidity: 5% ~95% Non-condensing

◆ Color: Navy blue

◆ Dimensions: Surface mount: 4 1/2" x 2 3/4" x 1 5/8" (114 W x 70 H x 41 D mm)

◆ Interface: RS485
